FRAME
FRAME
HPA Advanced Hydroform, ATG, ETC 4-Link, AXH
MAAT
Size Split: 27.5: XS // 29: S, M, L, XL
SUSPENSION
VERENDE VOORVORK
RockShox Recon Gold RL Air, Tapered, 15x110mm, 130mm
DEMPER
RockShox Deluxe Select+, 190x45mm, Rebound Adjust, Lockout
DEMPER-HARDWARE
Top: 40x8mm, Bottom: 22x8mm
DRIVETRAIN & BRAKES
REMSYSTEEM
Shimano BR-MT500, Hydr. Disc Brake (180/180)
ACHTERDERAILLEUR
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SCHAKELAAR
Shimano Deore SL-M6100, Rapidfire-Plus
TRAPAS
Shimano BB-MT500PA, 92mm Pressfit
CRANKS
Shimano FC-MT511, Boost, 30T
CASSETTE
Shimano Deore CS-M6100, 10-51T
KETTING
Shimano CN-M6100
COCKPIT
STUUR
Newmen Evolution SL 318.25, 760mm
STUURPEN
Newmen Evolution 318.4, 31.8mm
HANDVATTEN
ACID React Pro
BALHOOFDLAGERS
VP Tapered, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
WHEELS
WIELEN
Fulcrum Red 77, 28/28 Spokes, 15x110mm / 12x148mm, Tubeless Ready
BANDEN
Maxxis Forekaster, EXO, Tubeless Ready, 2.35
FINISHING KIT
ZADELPEN
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
ZADEL
Natural Fit Venec Lite
